A Technical SEO Guide to Lighthouse Performance Metrics

Maybe you’re here because you’re a die-hard fan of performance metrics. Or maybe you don’t know what Lighthouse is and are too afraid to ask.

Either is an excellent option. Welcome!

For this merry adventure into demystifying developer documentation, I’ve recruited Technical SEO and Google Data Studio nerd Rachel Anderson.

Together, we’re hoping to take your performance improvement efforts from “make all the numbers green“ to some clear and meaningful action items.

We’re going to look at:

• What the heck is Lighthouse? (In case you didn’t know and were afraid to ask.)
• Updates to how Performance Score is calculated (versions 6 and 7).
• How to test performance using Lighthouse.
• What metrics comprise Lighthouse’s Performance score.
• What those metrics mean.
• How to improve them.

What Is Lighthouse?

Lighthouse is an open-source auditing tool that provides standardized scores across five areas:

• Performance.
• Progressive Web App.
• Best Practices.
• Accessibility.
• SEO.

For the purposes of this article, we’re going to use the name Lighthouse to refer to the series of tests executed by the shared Github repo, regardless of the execution method.

Lighthouse runs performance tests using emulated data, also known as lab data.

This is performance data collected within a controlled environment with predefined device and network settings.

Lab data is helpful for debugging performance issues. It does not mean that the experience on your local machine in a controlled environment represents the experiences of real humans in the wild.

Updates to Lighthouse: Web Core Vitals

On May 5, 2020, the Chromium project announced a set of three metrics with which the Google-backed open-source browser would measure performance.

The metrics, known as Web Vitals, are part of a Google initiative designed to provide unified guidance for quality signals.

The goal of these metrics is to measure web performance in a user-centric manner.

Within two weeks, Lighthouse v6 rolled out with a modified version of Web Core Vitals at the heart of the update.

July 2020 saw Lighthouse v6’s unified metrics adopted across Google products with the release of Chrome 84.

Chrome DevTools Audits panel was renamed to Lighthouse. Pagespeed insights and Google Search Console also reference these unified metrics.

Web Core Vitals comprise 55% of Lighthouse’s weighted performance score. This change in focus sets new, more refined goals.

Overall, most pages saw minimal impact with 83.32% of tests shifting ten points or less on the shift to v6.

Version 7 is currently out on Github and slated for large scale rollout with the stable Chrome 89 release in March 2021.

How to Test Performance Using Lighthouse

Methodology Matters

Out of the box, Lighthouse audits a single page at a time.

A single page score doesn’t represent your site, and a fast homepage doesn’t mean a fast site.

Test multiple page types within your site.

Identify your major page types, templates, and goal conversion points (signup, subscribe, and checkout pages).

Example Page Testing Inventory

Before you begin optimizing, run Lighthouse on each of your sample pages and save the report data.

Record your scores and the to-do list of improvements.

Prevent data loss by saving the JSON results and utilizing Lighthouse Viewer when detailed result information is needed.

Get Your Backlog to Bite Back Using ROI

Getting development resources to action SEO recommendations is hard.

An in-house SEO could destroy their pancreas by having a birthday cake for every backlogged ticket’s birthday. Or at least learn to hate cake.

In my experience as an in-house enterprise SEO, the trick to getting performance initiatives prioritized is having the numbers to back the investment.

This starting data will become dollar signs that serve to justify and reward development efforts.

Chances are you’re going to have more than one area flagged during tests. That’s okay!

If you’re wondering which changes will have the most bang for the buck, check out the Lighthouse Scoring Calculator.

How to Run Lighthouse Tests

This is a case of many roads leading to Oz. Sure, some scarecrow might be particularly loud about a certain shade of brick but it’s about your goals.

Looking to integrate SEO tests into the release process? Time to learn some NPM.

Have less than five minutes to prep for a prospective client meeting? A couple of one-off reports should do the trick.

Whichever way you execute, default to mobile unless you have a special use-case for desktop.

For One-Off Reports: Chrome Devtools

Test one page at a time with the Lighthouse panel in Chrome DevTools. Because the report will be emulating a user’s experience using your browser, use an incognito instance with all extensions, and the browser’s cache disabled.

Pro tip: Create a Chrome profile for testing. Keep it local (no sync enabled, password saving, or association to an existing Google account) and don’t install extensions for the user.

How to Run a Test Lighthouse Using Chrome DevTools

1. 1. Open an incognito instance of Chrome.
   2. Navigate to the Network panel of Chrome Dev Tools (Command + Option + I on Mac or Control + Shift + I on Windows and Linux).
   3. Tick the box to disable cache.
   4. Navigate to the Lighthouse panel.
   5. Click Generate Report.
   6. Save the file.

Pros of Running Lighthouse From DevTools

Cons of Running Lighthouse From DevTools

• One report at a time.
• Requires you to manually save results.

For Testing the Same Pages Frequently: web.dev

It’s just like DevTools but you don’t have to remember to disable all those pesky extensions!

1. Visit web.dev/measure/.
2. Sign in using your Google account.
3. Enter your URL.
4. Click Run Audit.

Pros of Running Lighthouse From web.dev

• Captures a nifty timeline of results! (As long as you’re logged in).

Cons of Running Lighthouse From web.dev

• One report at a time.
• You’ll need to remember which URLs you’re tracking over time.

For Testing at Scale (and Sanity): Node Command Line

1. Install npm.
   (Mac Pro tip: Use homebrew to avoid obnoxious dependency issues.)
2. Install the Lighthouse node module with

   npm install -g lighthouse

3. Run a single text with

   lighthouse <url>

4. Run tests on lists of usings by running tests programmatically.

Pros of Running Lighthouse From Node

• Many reports can be run at once.
• Can be set to run automatically to track change over time.

Cons of Running Lighthouse From Node

• Requires some coding knowledge.
• More time-intensive setup.

Lighthouse Performance Metrics Explained

In versions 6 and 7, Lighthouse’s performance score made of seven metrics with each contributing a percentage of the total performance score.

First Input Delay, the field data equivalent to TBT, has different thresholds.

Long Tasks & Total Blocking Time

TBT measures long tasks—those taking longer than 50ms.

When a browser loads your site, there is essentially a single line queue of scripts waiting to be executing.

Any input from the user has to go into that same queue.

When the browser can’t respond to user input because other tasks are executing, the user perceives this as lag.

Essentially, long tasks are like that person at your favorite coffee shop who takes far too long to order a drink.

Like someone ordering a 2% venti four-pump vanilla, five-pump mocha whole-fat froth, long tasks are a major source of bad experiences.

What Causes a High TBT on Your Page?

Heavy JavaScript.

That’s it.

How to See TBT Using Chrome Devtools

1. Open the page in Chrome.
2. Navigate to the Performance panel of Dev Tools (Command + Option + I on Mac or Control + Shift + I on Windows and Linux).
3. Click the reload button to start a performance trace.
4. Look for the red markers in the right-hand corner of tasks.  These indicate long tasks that took more than 50ms.

How to Fix Poor TBT

• Break up Long Tasks.
• Optimize your page for interaction readiness.
• Use a web worker.
• Reduce JavaScript execution time.

Resources For Improving TBT

First Contentful Paint (FCP)

What it represents: FCP marks the time at which the first text or image is painted (visible).

Lighthouse Performance score weighting: 15%

What it measures: The time when I can see the page I requested is responding. My thumb can stop hovering over the back button.

How it’s measured: Your FCP score in Lighthouse is measured by comparing your page’s FCP to FCP times for real website data stored by the HTTP Archive. Your FCP increases if it is faster than other pages in the HTTP Archive.

Is First Contentful Paint a Web Core Vital? No

FCP Scoring

Goal: achieve FCP in < 2 seconds.

What Elements Can Be Part of FCP?

The time it takes to render the first visible element to the DOM is the FCP. Anything that happens before an element that renders non-white content to the page (excluding iframes) is counted toward FCP.

Since iframes are not considered part of FCP, if they are the first content to render, FCP will continue counting until the first non-iframe content loads, but the iframe load time isn’t counted toward the FCP.

The documentation around FCP also calls out that is often impacted by font load time and there are tips for improving font loads.

How to Define FCP Using Chrome Devtools

1. Open the page in Chrome.
2. Navigate to the Performance panel of Dev Tools  (Command + Option + I on Mac or Control + Shift + I on Windows and Linux).
3. Click on the FCP marker in the Timings section.
4. The summary tab has a timestamp with the FCP in ms.

How to Improve FCP

In order for content to be displayed to the user, the browser must first download, parse, and process all external stylesheets it encounters before it can display or render any content to a user’s screen.

The fastest way to bypass the delay of external resources is to use in-line styles for above-the-fold content.

To keep your site sustainably scalable, use an automated tool like penthouse and Apache’s mod_pagespeed. These solutions will come with some restrictions to functionalities, require testing, and may not be for everyone.

Universally, we can all improve our site’s time to First Contentful Paint by reducing the scope and complexity of style calculations.

If a style isn’t being used, remove it. You can identify unused CSS with Chrome Dev Tool’s built-in Code Coverage functionality.

Use better data to make better decisions.

Similar to TTI, you can capture real user metrics for FCP using Google Analytics to correlate improvements with KPIs.

Speed Index

What it represents: how much is visible at a time during load.

Lighthouse Performance score weighting: 15%

What it measures: The Speed Index is the average time at which visible parts of the page are displayed.

How it’s measured: Lighthouse’s Speed Index measurement comes from a node module called Speedline.

You’ll have to ask the kindly wizards at webpagetest.org for the specifics but roughly, Speedline scores vary by the size of the viewport (read as device screen) and has an algorithm for calculating the completeness of each frame.

Is Speed Index a Web Core Vital? No

SI Scoring

Goal: achieve SI in < 4.3 seconds.

How to Improve SI

Speed score reflects your site’s Critical Rendering Path. A “critical” resource means that the resource is required for the first paint or is crucial to the page’s core functionality.

The longer and denser the path, the slower your site will be to provide a visual page. If your path is optimized, you’ll give users content faster and score higher on Speed Index.

How the Critical Path Affects Rendering

Lighthouse recommendations commonly associated with a slow Critical Rendering Path include:

• Minimize main-thread work.
• Reduce JavaScript execution time.
• Minimize Critical Requests Depth.
• Eliminate Render-Blocking Resources.
• Defer offscreen images.

Time to Interactive

What it represents: Load responsiveness; identifying where a page looks responsive but isn’t yet.

Lighthouse Performance score weighting: 15%

What it measures: The time from when the page begins loading to when its main resources have loaded and are able to respond to user input.

How it’s measured:  TTI measures how long it takes a page to become fully interactive. A page is considered fully interactive when:

• The page displays useful content, which is measured by the First Contentful Paint.
• Event handlers are registered for most visible page elements.
• The page responds to user interactions within 50 milliseconds.

Is Time to Interactive a Web Core Vital? No

TTI Scoring

Goal: achieve TTI score of less than 3.8 seconds.

Cumulative Layout Shift (CLS)

What it represents: A user’s perception of a page’s visual stability.

Lighthouse Performance score weighting: 5%*

* Expect CLS to increase in weighting as they work the bugs out. Smart bet says Q4 2021.

What it measures: It quantifies shifting page elements through the end of page load.

How it’s measured: Unlike other metrics, CLS isn’t measured in time. Instead, it’s a calculated metric based on the number of frames in which elements move and the total distance in pixels the elements moved.

CLS Scoring

Goal: achieve CLS score of less than 0.1.

What Elements Can Be Part of CLS?

Any visual element that appears above the fold at some point in the load.

That’s right –  if you’re loading your footer first and then the hero content of the page, your CLS is going to hurt.

Causes of Poor CLS

• Images without dimensions.
• Ads, embeds, and iframes without dimensions.
• Dynamically injected content.
• Web Fonts causing FOIT/FOUT.
• Actions waiting for a network response before updating DOM.

How to Define CLS Using Chrome Devtools

1. Open the page in Chrome.
2. Navigate to the Performance panel of Dev Tools  (Command + Option + I on Mac or Control + Shift + I on Windows and Linux).
3. Hover and move from left to right over the screenshots of the load (make sure the screenshots checkbox is checked).
4. Watch for elements bouncing around after the first paint to identify elements causing CLS.

How to Improve CLS

Once you identify the element(s) at fault, you’ll need to update them to be stable during the page load.

For example, if slow-loading ads are causing the high CLS score, you may want to use placeholder images of the same size to fill that space as the ad loads to prevent the page shifting.

Some common ways to improve CLS include:

• Always include width and height size attributes on images and video elements.
• Reserve space for ad slots (and don’t collapse it).
• Avoid inserting new content above existing content.
• Take care when placing non-sticky ads near the top of the viewport.
• Preload fonts.

CLS Resources

Conclusion

The complexity of performance metrics reflects the challenges facing all sites.

We use performance metrics as a proxy for user experience – that means factoring in some unicorns.

Tools like Google’s Test My Site and What Does My Site Cost? can help you make the conversion and customer-focused arguments for why performance matters.

Hopefully, once your project has traction, these definitions will help you translate Lighthouse’s single performance metric into action tickets for a skilled and collaborative engineering team.

Track your data and shout it from the rooftops.

As much as Google struggles to quantify qualitative experiences, SEO professionals and devs must decode how to translate a concept into code.

Test, iterate, and share what you learn! I look forward to seeing what you’re capable of, you beautiful unicorn.
